PRF Radon Mitigation Fan

In-line Duct Fan Series

PRF

Model Features

  • Duct lips sized for easy fit with standard PVC couplings typically used in radon mitigation applications
  • Fully sealed, high quality plastic housing
  • Large, easily accessible, watertight electrical box for unobstructed wiring process
  • Easily mount on duct pipe or use heavy-duty metal mounting bracket (sold separately)
  • Significantly less expensive than comparable alternatives
  • Thermal overload protection
  • HVI Certified Performance
  • cETLus certified

HVI Certified Performance   cETLus certified

Model Overview

PRF-Radon Mitigation fans are specifically designed for radon mitigation. The fully-sealed plastic fans feature backward inclined centrifugal blower/motors capable of handling up to 1" of static pressure. The PRF series has duct lips sized for easy fit with standard PVC couplings typically used in radon mitigation applications. Additionally the PRF was engineered with large, easily accessible, watertight electrical boxes for unobstructed wiring process.

5-year fan housing and motor warranty

Size Duct Dia. (in) Max. CFM Nom. RPM Voltage / Frequency Max. Watts Current Max. SP (in W.G.) Max. Temp. of Transported Air Shipping Weight
100 4 169 3080 120V / 60Hz 92W 0.77A 1 140°F 6.6 lbs
Dimensional Drawing PRF
Model A B C
100 4" or 5" 10-9/16" 10-3/4"

Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Part Description
MD Motorized Backdraft Damper   Download
PR-BRKT Metal mounting bracket for PRF fan
PR-M PRF U-Tube manometer & Label Kit
PRFIK-43 PRF Installation Kit, 4x3 Couplings & Manometer
PRFIK-44 PRF Installation Kit, 4x4 Couplings & Manometer
PRFIK-64 PRF Installation Kit, 6x4 Couplings & Manometer
