TD-MIXVENT In-line Mixed Flow Duct Fan

In-line Duct Fan Series

DA

Model Features

  • Exhaust air up to 2,630 CFM with static pressure capabilities to 1" w.g.
  • Mixed flow impeller for excellent airflow to pressure performance ratio
  • Ideal for applications where space is limited
  • AMCA Seal for Air Performance
  • cULus Listed
  • ENERGY STAR® qualified

AMCA Seal for Air Performance   cULus Listed   ENERGY STAR Qualified  HVI Certified

Model Overview

The TD-MIXVENT series are in-line duct fans specially designed to maximize the airflow performance with minimal noise levels in a small, compact housing. This makes the TD-MIXVENT series the ultimate solution for small to medium sized ventilation installations which require a high airflow to pressure ratio and occupy minimum space (e.g., false ceiling voids, cabinets and many other limited space environments).

TD-MIXVENT have been designed with the professional contractor/engineer in mind. All models include a "removable body" feature that enables the motor-impeller assembly to be completely removed or replaced without the need to interfere with the attached ducting. These models incorporate a powerful mixed flow impeller and internal air vanes located at the discharge end of the fan housing. This impeller and guide vane combination provides a smooth laminar airflow which in turn minimizes turbulence and noise and generates excellent airflow to static pressure performance ratio.

The unique design of the support brackets allows the motor and impeller assembly to be fitted or removed without dismantling the adjacent ducting, therefore facilitating any installation or maintenance. The internal aerodynamic design of the fan enables the unit to generate large air volumes and pressures with the minimum of in-duct or radiated noise. These fans offer an ideal in-line duct fan solution for a wide range of HVAC ventilation applications.

5-year fan housing and motor warranty

LS = Low Speed / HS = High Speed


AMCA Certified Performance

Size Duct Dia. Max. CFM Nom. RPM Voltage / Frequency Max. Watts Current (Amps) Max. SP Max. Temp. Min. Temp. Avg. Ship Weight (lbs)
100 4" 101 2516 120V / 60Hz 26 0.45 0.4" 104°F -4°F 4
100X1 4" 135 2500 120V / 60Hz 33 0.24 0.55" 104°F -4°F 6
125 5" 197 2146 120V / 60Hz 38 0.72 0.55" 104°F -4°F 6
150 6" 293 2289 120V / 60Hz 65 0.54 1.15" 140°F -4°F 9
200 8" 538 2781 120V / 60Hz 184 0.8 1.625" 140°F -4°F 13
250 LS 10" 541 2400 115V / 60Hz 162 2.2A 2.03" 140°F -4°F 21
250 HS 10" 754 3200 115V / 60Hz 241 2.2A 2.53" 140°F -4°F 21
315 LS 12.4" 751 2000 115V / 60Hz 208 2.3A 1.62" 140°F -4°F 31
315 HS 12.4" 1050 2500 115V / 60Hz 335 2.3A 2.95" 140°F -4°F 31
355 14" 2089 1536 115V / 60Hz 522 3.9A 1.0" 104°F -4°F 68
400 16" 3127 1559 115V / 60Hz 916 6.3A 1.2" 104°F -4°F 78

LS = Low Speed / HS = High Speed


HVI Certified Performance

Size RPM Max CURRENT (Amps) Volts Watts @ 0.2" w.g. Speed 0 0.125 0.2 0.25 0.3 0.375 0.4 0.5 0.75 1 1.25 1.5 Duct Dia.(inches)
100 2564 0.45 120 23.5 HS 101 84 70 57 34 18 15 1 - - - - 4
100X1 2352 0.23 120 26.4 HS 131 112 100 90 78 57 44 27 - - - - 4
125 2392 0.32 120 37.8 HS 200 177 160 146 129 89 78 41 - - - - 5
150 2290 0.54 120 62.1 HS 295 272 260 251 242 229 224 204 122 33 - - 6
200 2022 1.03 120 113 HS 475 448 430 418 406 385 378 352 264 142 - - 8
250 HS 2721 2.27 120 210 HS 815 782 760 744 726 699 690 654 561 449 322 241 10
250 LS 1982 1.32 120 147 LS 612 557 520 493 463 417 401 329 233 178 135 75 10
315 HS 2559 2.49 120 303 HS 1027 965 940 925 908 875 862 803 672 505 368 291 12
315 LS 1888 1.55 120 194 LS 811 726 660 633 592 532 512 421 234 168 110 51 12

HVI certified performance is at "0.2" of static pressure

Dimensional drawing for the TD model size 100 to 315.

TD-MIXVENT Specifications (Size 100 to 315)

Dimensional data is displayed in inches.

Size X A B C D E F G H
100 5-15/16 9-1/8 5-7/16 3-3/4 3-7/8 3-1/4 3-3/4 1-7/8 2-1/16
100X1 7-3/8 11-15/16 6-15/16 4-1/2 3-13/16 3-15/16 3-9/16 3-1/8 2-3/8
125 7-3/8 10-3/16 6-15/16 4-1/2 4-13/16 3-15/16 3-9/16 3-1/8 2-3/8
150 8-3/8 11-5/8 7-7/8 5 5-13/16 4-7/16 5-1/8 3-1/8 2-3/8
200 9-3/16 11-7/8 8-9/16 5-9/16 7-13/16 4-7/8 5-1/2 3-15/16 3-11/16
250 11-7/16 15-3/16 10-11/16 7-9/16 9-3/4 6-1/8 6-5/8 5-11/16 5-1/2
315 14 17-11/16 13-1/4 8-13/16 12-5/16 7-3/8 8-1/4 7-3/16 7
Dimensional drawing for the TD model size 355 to 400.

TD-MIXVENT Specifications (Size 355 to 400)

Dimensional data is displayed in inches.

Size A B C D E F G H I J K
355 14-13/16 9-3/8 17-3/4 8-13/16 16-3/4 13-15/16 6-5/16 14-1/2 18-11/16 13-3/8 5/16
400 16 9-13/16 19-3/8 10-1/2 19-3/16 15-11/16 6-5/16 16-3/4 21-1/2 14-9/16 5/16

TD-MIXVENT Fan Kits

The TD-MIXVENT fan kits provide all the hardware needed to complete a simple in-line ducted ventilation installation. The kit includes a powerful TD in-line fan, exterior grilles and interior grilles (with or without lights).

All TD product kits have a standard 5-year warranty (Light Bulbs are not included in the warranty).

Standard Exhaust Kit

KIT-TD100

KIT-TD100

  • 1 TD100 exhaust fan
  • 1 plastic round grille (PG-100)
  • 1 exterior louvered grille (PER-100W)
  • Integral mounting bracket
KIT-TD150

KIT-TD150

  • 1 TD150 exhaust fan
  • 1 plastic round grille (PG-150)
  • 1 exterior louvered grille (PER-150W)
  • Integral mounting bracket

Deluxe Exhaust Kit

KIT-TD150-DV

KIT-TD150-DV

  • 1 TD150 exhaust fan
  • 2 plastic round grilles (PG-150)
  • 1 exterior louvered grille (PER-150W)
  • 1 Y-fitting (SY-6)
  • Integral mounting bracket

Lighted Deluxe Exhaust Kit

KIT-TD150L

KIT-TD150L

  • 1 TD150 exhaust fan
  • 2 Vent Lights with LED Bulb (VLED-100)
  • 1 Y-fitting (SY44-6)
  • Integral mounting bracket
KIT-TD150H

KIT-TD150H

  • 1 TD150 exhaust fan
  • 2 Vent Lights with Halogen Bulb (VLH-100)
  • 1 Y-fitting (SY44-6)
  • Integral mounting bracket
KIT-TD150F

KIT-TD150F

  • 1 TD150 exhaust fan
  • 2 Vent Lights with Fluorescent Bulb (VLF-100)
  • 1 Y-fitting (SY44-6)
  • Integral mounting bracket
