PCD
DC Motor Models

Premium CHOICE Series New Product Coming Soon

PCD - with DC Motor

Model Features

  • Extremely quiet operation 0.3 to 1.5 Sones
  • Brushless DC motor for long life
  • Motor rated for 60,000 hours continuous on High/Low-speed delay timer
  • 6" Duct connector with built-in backdraft damper
  • Robust steel housing
  • Attractive, sturdy grille
  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified
  • Ecowatt®

cETLus   ENERGY STAR   HVI   Ecowatt

Model Overview

PCD fans feature the most efficient DC motors available to help improve indoor air quality and increase your home's durability by quickly exhausting contaminants and excess moisture that can cause health issues, mold growth, and structural damage. With built-in control boards, the PCD models allow you to CHOOSE your airflow. The DC fans are available with humidity sensing, motion sensing, and VOC sensing options built-in.

6-year warranty

Technical Specifications

Model Speed Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sound (Sones) Voltage / Frequency Wattage Current (Amps) Avg. Ship Weight (lbs)
PCD80XH High 4" 80 61 1.5 120V / 60Hz 22 0.35 7
Low 40 20 0.7 10

Toggle Switch Settings (PCD110X Models Only)

The built-in switch and duct connector options allow you to set the PCD fan to the required airflow. Use the below chart to adjust your switch connections by changing the toggle switch to match the diagram.

PCD Toggle Switch Settings
All Variants Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight
PCD110X 6" 40 - <0.3 120V / 60Hz 9.6 4.2 0.09A 11 lbs
90 51 0.5 12.2 8.1 0.16A
110 78 0.9 11.4 10.3 0.20A
120 91 1.2 10.8 12.2 0.22A
140 113 1.5 9.4 15.6 0.27A

Plug-&-Play Grille Options

Metal Grille

PCMG
PCMG - Metal Grille
  • 13 x 14" metal grille
  • Ideal for commercial applications
  • Only Compatible with PCD110X Models

Lighted Grille Kits

PCLK
PCLK - CFL Lighted Grille Kit
  • 13 watt GU24 bulb (2700K/900 lumens)
  • 4 watt night light bulb
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
  • Only Compatible with PCD110X Models
PCLEDK
PCLEDK - LED Lighted Grille Kit
  • 11 watt LED array (4100K/1100 lumens)
  • 2 watt LED night light setting (200 lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
  • Only Compatible with PCD110X Models
PCVLEDK

PCVLEDK - LED Lighted Grille Kit

  • 13 Watt LED Light (4100K/1100 Lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
  • Only Compatible with PCD80XH Models
PCVLK

PCVLK - CFL Lighted Grille Kit

  • 13 watt GU24 bulb (2700K/900 lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
  • Only Compatible with PCD80XH Models

Sensing Grille Kits

PCDLMG
PCDLMG - Motion Sensing Lighted Grille Kit
  • Compatible with PCD110XM and PCD110XMH
  • 13 Watt GU24 Bulb (2700K/900 Lumens)
  • 4 Watt Night Light Bulb
  • Automatically turns on fan when motion is sensed
  • Adjustable Time Delay Shut-Off from 3 to 30 Minutes
  • Simple Plug-In Receptacle in Fan Housing
  • Can be installed with New or Pre-Installed Fan
  • Only Compatible with PCD110X Models

Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Note: All Accessories are compatible with the PCD110X Models unless otherwise noted in the part description.

Radiation Dampers & Kits

PCRD Ceiling Radiation Damper SubmittalIOM
PCLKRD Ceiling Radiation Damper Kit with PCLK Submittal
PCLEDKRD Ceiling Radiation Damper Kit with PCLEDK Submittal
PCMGKRD Ceiling Radiation Damper Kit with PCD110M and PCD110MH
PCD110MRD Ceiling Radiation Damper for PCD110M and PCD110MH Submittal
PCVRD Ceiling Radiation Damper (ONLY COMPATIBLE WITH PCD80XH) Submittal
PCVLEDKRD Ceiling Radiation Damper Kit with PCVLEDK (ONLY COMPATIBLE WITH PCD80XH) Submittal

Electrical Controls

PC3S 3-Switch Control Submittal
FLTD-60 Fan/Light Delay Timer Switch Submittal
SRT-30 Rotary Spring Wound Timer Submittal
EPBT-60 Electronic Push Button Timer Submittal
FT622 ASHRAE 62.2 Bath Fan Ventilation Control Submittal
FT247 Programmable Fan Timer Submittal

General Accessories

PER-W Plastic Louvered Shutter Submittal
GRA Aluminum Exterior Fixed Grilles Submittal
RC Roof Cap Submittal
ME Round Adjustable Metal Elbow Submittal
DC Duct Connector
WC Worm Clamp

Replacement Parts

PCDC4 Replacement 4" Duct Connector (ONLY COMPATIBLE WITH PCD80XH)
PCDC6 Replacement 6" Duct Connector
Premium CHOICE Series Brochure
General Catalog Section
Submittal (PCD80XH)
Submittal (PCD110X with All Variations)
IOM (PCD80XH)
IOM (PCD110X)
IOM (PCD110XH)
IOM (PCD110XIAQS)
IOM (PCD110XM)
IOM (PCD110XMH)
Connection Wiring Diagram (Premium CHOICE Series with DC Motor)
PCD110X (all Product Variants)
PCRD: Radiation Damper
  • Residential Bathroom Exhaust
  • Commercial Bathroom Exhaust
  • Local Exhaust
  • Dwelling Unit Ventilation
How to Install Premium CHOICE Bathroom Fans
How to Wire Premium CHOICE Bathroom Fans
Premium CHOICE Plug-&-Play Options
