L3E and L3S Belt Drive Sidewall Propeller Exhaust/Supply Fans
Wall Mounted Fan Series
Model Features
- Exhaust air up to 85,000 CFM in high static pressure applications up to 1" w.g.
- Heavy-gauge galvanized steel panel
- Die formed galvanized steel blades
- AMCA Air and Sound Licensed
- cULus 705 Listed
Model Overview
L3E (exhaust) and L3S (supply) are high capacity wall mounted belt driven propeller fans rated from 35,000 to 85,000, with static pressure capability up to 1" W.G. Their primary application is the exhaust of large volumes of air at relatively moderate static pressure from commercial, industrial and agricultural buildings such as manufacturing and assembly plants, warehouses, foundries, mills, boiler rooms and equipment rooms.
Wall mounting provides an easy and economical installation. Belt driven fans provide large volumes of air at low fan speed and low noise levels and afford quick, easy performance adjustments. All required accessories are available with Model L.
See Model L - Construction Level 1, or Construction Level 2, for lower static pressures and lighter duty requirements which are more economical.
2-year fan housing warranty, 1-year motor warranty
| Size | Max HP | CFM Range | Max SP | Avg. Ship Weight (lbs) |
| 42 | 7-1/2 HP | 21683 to 31344 | 3/4" | 260 |
| 48 | 10 HP | 23603 to 43005 | 3/4" | 330 |
| 54 | 15 HP | 19763 to 59940 | 3/4" | 500 |
| 60 | 15 HP | 28162 to 68178 | 1" | 530 |
| 72 | 15 HP | 11736 to 85089 | 1" | 600 |
| Model Size | A | B | C | D | E | F | Damper O.D. Sq. Flange |
| 42 | 48" | 2" | 7-1/2" | 1-1/4" | 16" | 24" | 46-1/2" |
| 48 | 54" | 2" | 7-1/2" | 1-1/4" | 16" | 24" | 52-1/2" |
| 54 | 60" | 2" | 7-1/2" | 1-1/4" | 20" | 26" | 58-1/2" |
| 60 | 66" | 2" | 7-1/2" | 1-1/4" | 20" | 26" | 64-1/2" |
| 72 | 80" | 2" | 8" | 1-1/4" | 24" | 28" | 78-1/2" |
Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.
Standard Accessories
| Aluminum Construction | ||
| Center Pivot Motorized | ||
| Dampers for Exhaust and Supply | ||
| Disconnect Switches | ||
| Extended Lube Lines | ||
| Factory Wiring | ||
| Filtered Wall Housing | Submittal | |
| Gravity Dampers for Exhaust and Supply | ||
| Motorized Dampers for Exhaust and Supply | ||
| Mounting Angles | ||
| Rainhoods/Weatherhoods | ||
| Ventilation Gas Detectors | Submittal | IOM |
- General / Clean Air
- Spark Resistant
