L2E and L2S Belt Drive Sidewall Propeller Exhaust/Supply Fans
Wall Mounted Fan Series
Model Features
- Exhaust air up to 47,000 CFM in high static pressure applications up to 3/4" w.g.
- Heavy-gauge galvanized steel panel
- Die formed galvanized steel blades
- Sized for minimum 150% of drive horsepower
- AMCA Air and Sound Licensed
- cULus 705 Listed
Model Overview
L2E (exhaust) and L2S (supply) are high capacity wall mounted belt driven propeller fans rated from 5,000 to 47,000 CFM, with static pressure capability up to 3/4" w.g. Their primary application is the exhaust of large volumes of ventilation air from commercial and light industrial buildings such as manufacturing and assembly plants, warehouses, parking garages, gymnasiums, equipment rooms, distribution centers and OEM applications.
Wall mounting provides an easy and economical installation. All necessary accessories are available. Belt driven fans provide large volumes of air at low fan speed and low noise levels and afford quick, easy performance adjustments.
See Model L - Construction Level 3 for higher static pressures and heavier construction designs or Model L - Construction Level 1 for your lighter duty ventilation requirements.
2-year fan housing warranty, 1-year motor warranty
| Size | Max HP | CFM Range | MAX SP | Avg. Ship Weight (lbs) |
| 24 | 2 HP | 2733 to 11273 | 5/8" | 120 |
| 30 | 3 HP | 4378 to 17109 | 1/2" | 180 |
| 36 | 5 HP | 2429 to 23846 | 3/4" | 215 |
| 42 | 5 HP | 3612 to 27472 | 3/4" | 235 |
| 48 | 5 HP | 7002 to 34010 | 3/4" | 300 |
| 54 | 5 HP | 10747 to 41715 | 5/8" | 400 |
| 60 | 5 HP | 15136 to 47161 | 1/2" | 490 |
| Model Size | A | B | C | D | E | F | Damper O.D. Sq. Flange |
| 24 | 30" | 2" | 7-1/2" | 1-1/4" | 15" | 23" | 28-1/2" |
| 30 | 36" | 2" | 7-1/2" | 1-1/4" | 15" | 24" | 34-1/2" |
| 36 | 42" | 2" | 7-1/2" | 1-1/4" | 15" | 24" | 40-1/2" |
| 42 | 48" | 2" | 7-1/2" | 1-1/4" | 16" | 24" | 46-1/2" |
| 48 | 54" | 2" | 7-1/2" | 1-1/4" | 16" | 24" | 52-1/2" |
| 54 | 60" | 2" | 7-1/2" | 1-1/4" | 20" | 26" | 58-1/2" |
| 60 | 66" | 2" | 7-1/2" | 1-1/4" | 20" | 26" | 64-1/2" |
Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.
Standard Accessories
| Aluminum Construction | ||
| Center Pivot Motorized | ||
| Dampers for Exhaust and Supply | ||
| Disconnect Switches | ||
| Extended Lube Lines | ||
| Factory Wiring | ||
| Filtered Wall Housing | Submittal | |
| Gravity Dampers for Exhaust and Supply | ||
| Motorized Dampers for Exhaust and Supply | ||
| Mounting Angles | ||
| Rainhoods/Weatherhoods | ||
| Ventilation Gas Detectors | Submittal | IOM |
- General / Clean Air
- Spark Resistant
