ARE and ARSDome Axial Power Roof Exhaust/Supply Fans
Roof Top Fan Series
Model Features
- Exhaust air up to 2,827 CFM in static pressure applications up to 3/4" w.g.
- Low profile attractive spun aluminum exterior
- Direct drive units have low sound levels and quiet operation
- AMCA Air and Sound Licensed
- UL 705 Listed
Model Overview
The AR series offers powerful axial exhaust (ARE) or supply (intake) (ARS) performance in a compact, lightweight and easy to install roof mounted design. Available in 4 model sizes, the AR series has a CFM range from 167 to 2,827 CFM, with static pressure capability up to 3/4".
The direct drive design has no belts or fan bearings to maintain or adjust and consequently requires very little maintenance. The AR series is an excellent choice for factories, shops, restaurants, bathrooms, offices, schools and other similar applications where light to moderate static pressures are present.
The low contour designs and all aluminum housing provide a modern, clean appearance in addition to excellent performance and durability..
5-year fan housing warranty, 1-year motor warranty
ARE Specifications
| Size | Max HP | CFM Range | Max SP | Avg. Ship Weight (lbs) |
| 120A | 1/4 HP | 521 to 1,804 | 3/4" | 42 |
| 121A | 1/4 HP | 207 to 1,220 | 1/2" | 42 |
| 160A | 1/3 HP | 685 to 2,606 | 3/4" | 55 |
| 161A | 1/4 HP | 455 to 1,782 | 1/2" | 55 |
| 201A | 1/4 HP | 584 to 2,827 | 3/4" | 75 |
ARS Specifications
| Size | Max HP | CFM Range | Max SP | Avg. Ship Weight (lbs) |
| 120A | 1/4 HP | 206 to 1,445 | 3/4" | 42 |
| 121A | 1/4 HP | 163 to 974 | 1/4" | 42 |
| 160A | 1/3 HP | 303 to 2,187 | 3/4" | 55 |
| 161A | 1/4 HP | 442 to 1,754 | 1/2" | 55 |
| 201A | 1/4 HP | 1,254 to 2,627 | 3/8" | 75 |
| Model Size | A | B | C | D | E | F |
| 120A to 121A | 28" | 16" | 8" | 3" | 24" | 15-3/4" |
| 160A to 161A | 32" | 18" | 8-1/2" | 3" | 28" | 19-3/4" |
| 201A | 36" | 20" | 9-3/4" | 3" | 32" | 23-3/4" |
Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.
Standard Accessories
| Automatic Damper | |
| Clip Lock Curb | Submittal |
| Curb Hinge Arrangment | |
| Insect Screen | |
| Motor Operated Damper | |
| Roof Curb | |
| Solid State Speed Control |
