UBRDRemote Drive Upblast Propeller Roof Exhaust Fan
Roof Top Fan Series
Model Features
- Exhaust air up to 72,000 CFM in static pressure applications up to 1/2" w.g.
- Straight-through air flow design results in maximum exhaust efficiency
- Motor and drives are located outside of the exhaust airstream
- Belt drives permit easy performance adjustments when needed
- cULus 705 Listed
Model Overview
UBRD units are high capacity belt driven roof mounted exhausters rated from 4,500 to 72,000 CFM. The motor and drives are located outside of the exhaust airstream, making these units especially suited for the removal of heated or contaminated air from commercial and industrial buildings or processes where these conditions exist. All models are capable of continuous operation exhausting air to 200°F.
The remote drive construction allows for easy rooftop belt and motor access for maintenance. For increased air performance (in clean conditions) with the same easy maintenance access, the UBRD is available without the belt and bearing enclosures.
Straight-through air flow design results in maximum exhaust efficiency. During operation, high air flow velocity opens butterfly dampers and prevents rain or snow from entering. Dampers close and cover the venturi opening when unit is not in use.
The roof mounted location eliminates interference with processes and equipment inside the building. It also permits locating the exhauster over a source of heated or contaminated air, allowing direct upward venting to the outside, unlike wall mounted exhausters which may move contaminated air through adjacent work spaces.
2-year fan housing warranty, 1-year motor warranty
UBRD Specifications
| Size | Max HP | CFM Range | Max SP | Avg. Ship Weight (lbs) |
| 24 | 2 HP | 4416 to 9200 | 1/2" | 310 |
| 30 | 3 HP | 7812 to 14508 | 1/2" | 340 |
| 36 | 3 HP | 10656 to 18816 | 1/2" | 430 |
| 42 | 5 HP | 15624 to 27261 | 1/2" | 490 |
| 48 | 10 HP | 16192 to 41216 | 1/2" | 640 |
| 54 | 10 HP | 22990 to 49210 | 1/2" | 840 |
| 60 | 10 HP | 25854 to 56730 | 1/2" | 1,000 |
| 72 | 10 HP | 37665 to 72726 | 3/8" | 1,550 |
| Model Size | A | B | C | D | E | F | G |
| 24 | 30" | 32" | 30" | 50" | 22" | 16" | 31" |
| 30 | 36" | 38" | 36" | 54" | 22" | 16" | 37" |
| 36 | 42" | 44" | 42" | 56" | 22" | 16" | 43" |
| 42 | 48" | 50" | 48" | 59" | 22" | 16" | 49" |
| 48 | 54" | 56" | 54" | 68" | 22" | 22" | 55" |
| 54 | 60" | 62" | 60" | 70" | 22" | 22" | 61" |
| 60 | 66" | 68" | 66" | 74" | 22" | 22" | 67" |
| 72 | 80" | 82" | 80" | 86" | 22" | 22" | 81" |
Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.
Standard Accessories
| Roof Curb | |
| Outlet Guard | |
| Disconnect Switch | |
| Magnetic Latches | |
| Heat/Smoke Vent | |
| Extended Grease Lines |
