TUB-HTTubeaxial Upblast Propeller Roof Exhaust Fan for Heat and Smoke Removal
Roof Top Fan Series
Model Features
- Exhaust air up to 57,000 CFM in static pressure applications up to 3/4" w.g.
- Motor and drives are located outside of the exhaust airstream
- Designed and tested for emergency heat and smoke removal
- Successfully passed heat test of 1000⪚F for 15 minutes and 500°F for over 4 hours
- Belt drives permit easy performance adjustments when needed
- UL 793 Listed as Power Ventilator for Smoke Control Systems
Model Overview
Tubeaxial Upblast Propeller Roof Exhauster for Heat and Smoke Removal Fans has been designed and tested for emergency heat and smoke removal. This design also lends itself to everyday non-emergency high capacity industrial and commercial roof exhaust applications. TUB-HT's successfully passed heat tests of 1000°F for fifteen (15) minutes, and 500°F for over four (4) hours by an independent testing agency. TUB-HT exceeds I.R.I (Industrial Risk Insurers) guidelines and is UL-793 Listed as "Power Ventilator for Smoke Control Systems."
The heavy-gauge design allows for years of standard commercial use and the dependability required in a fire emergency. The upblast configuration exhausts heat and smoke high above the roof line aiding in the access and capabilities of fire fighters. Unlike complete design dependence on gravity vents which are sometimes limited by air temperature and wind velocity, the TUB-HT in conjunction with gravity vents, will more effectively remove smoke, hot air, and gases when used in a properly designed system. In the event of electrical failure, the 165°F fusible link will activate the spring assisted damper doors to provide gravity ventilation. Fan CFM, sizing and location for both exhaust and supply air are an important part of the overall heat and smoke venting building design needs. Refer to I.R.I., NFPA (National Fire Protection Association), and local fire codes for help in proper system design. Final approval for the complete system design should be authorized by the local authority having jurisdiction.
Fan selections are available in 24, 30, 36, 42, 48, 54 and 60 inch sizes. Horsepower and CFM range to 57,000 CFM and 15HP. Units are tested in accordance with AMCA Standard 301 (sound) and AMCA 210 (air) in an AMCA certified laboratory. Every unit is completely assembled and factory tested for quality assurance prior to shipment.
1-year fan housing warranty, 1-year motor warranty
| Size | Max HP | CFM Range | Max SP | Avg. Ship Weight (lbs) |
| 24 | 2 HP | 4035 to 8693 | 5/8" | 500 |
| 30 | 5 HP | 6478 to 16225 | 3/4" | 600 |
| 36 | 5 HP | 7444 to 20849 | 3/4" | 1,000 |
| 42 | 7-1/2 HP | 11606 to 29490 | 3/4" | 1,100 |
| 48 | 10 HP | 11132 to 36776 | 3/4" | 1,300 |
| 54 | 15 HP | 18041 to 49325 | 3/4" | 1,580 |
| 60 | 15 HP | 19438 to 57143 | 3/4" | 1,700 |
| Model Size | A | B | C | D | E | F | G |
| 24 | 30" | 35" | 25-1/8" | 55-1/2" | 25" | 30-1/2" | 37" |
| 30 | 36" | 41" | 31-1/8" | 58-1/2" | 28" | 30-1/2" | 40" |
| 36 | 42" | 47" | 37-1/8" | 60-1/2" | 30" | 30-1/2" | 43" |
| 42 | 48" | 53" | 43-1/8" | 65-1/2" | 33" | 32-1/2" | 46" |
| 48 | 54" | 59" | 49-1/8" | 68-1/2" | 36" | 32-1/2" | 49" |
| 54 | 60" | 65" | 55-1/8" | 71-1/2" | 39" | 32-1/2" | 52" |
| 60 | 66" | 71" | 61-1/8" | 74-1/2" | 42" | 32-1/2" | 55" |
Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.
Standard Accessories
| Roof Curb | |
| Outlet Guard | |
| Inspection Door | |
| Heat/Smoke Vent | |
| Disconnect Switch |
