TUBTubeaxial Upblast Propeller Roof Exhaust Fan
Roof Top Fan Series
Model Features
- Exhaust air up to 60,116 CFM in static pressure applications up to 1" w.g.
- Straight-through air flow design results in maximum exhaust efficiency
- Motor and drives are located outside of the exhaust airstream
- Belt drives permit easy performance adjustments when needed
- cULus 705 Listed
Model Overview
Tubeaxial Upblast Propeller Roof Exhauster Fans are designed for high capacity industrial and commercial roof exhaust applications. The remote drive configuration of the TUB is especially suited for the removal of fumes, vapors, steam, dust, smoke and contaminated or heated air. Belt drive models are available for continuous operation in air temperatures to 200°F. For temperature ratings to 1000°F and/or IRI requirements refer to TUB-HT.
Capacities range from 6,210 to 60,116 CFM, with static pressure capability up to 1". Fan selections are available in 24, 30, 36, 42, 48, 54 and 60 inch sizes. Horsepower's range from 3/4 to 15HP. Blade selections is available in aluminum, steel, or fiberglass reinforced polypropylene. Units are tested in accordance with AMCA 301 (sound) and AMCA 210 (air) in an AMCA certified laboratory. Every unit is completely assembled and factory tested for quality assurance prior to shipment.
2-year fan housing warranty, 1-year motor warranty
TUB-A Specifications
| Size | Max HP | CFM Range | Max SP | Avg. Ship Weight (lbs) |
| 24 | 3 HP | 4595 to 10626 | 1" | 500 |
| 30 | 5 HP | 6919 to 17514 | 1" | 600 |
| 36 | 10 HP | 8630 tp 29020 | 1" | 1,000 |
| 42 | 10 HP | 8126 to 34310 | 1" | 1,100 |
| 48 | 10 HP | 15126 to 39574 | 1" | 1,300 |
| 54 | 15 HP | 22632 to 51252 | 1" | 1,580 |
| 60 | 15 HP | 28292 to 60116 | 1" | 1,700 |
TUB-P Specifications
| Size | Max HP | CFM Range | Max SP | Avg. Ship Weight (lbs) |
| 24 | 3 HP | 4595 to 10626 | 1" | 500 |
| 30 | 5 HP | 6919 to 17514 | 1" | 600 |
| 36 | 10 HP | 8630 tp 29020 | 1" | 1,000 |
| 42 | 10 HP | 8126 to 34310 | 1" | 1,100 |
| 48 | 10 HP | 15126 to 39574 | 1" | 1,300 |
| 54 | 15 HP | 22632 to 51252 | 1" | 1,580 |
| 60 | 15 HP | 28292 to 60116 | 1" | 1,700 |
| Model Size | A | B | C | D | E | F | G |
| 24 | 30" | 35" | 25-1/8" | 55-1/2" | 25" | 30-1/2" | 37" |
| 30 | 36" | 41" | 31-1/8" | 58-1/2" | 28" | 30-1/2" | 40" |
| 36 | 42" | 47" | 37-1/8" | 60-1/2" | 30" | 30-1/2" | 43" |
| 42 | 48" | 53" | 43-1/8" | 65-1/2" | 33" | 32-1/2" | 46" |
| 48 | 54" | 59" | 49-1/8" | 68-1/2" | 36" | 32-1/2" | 49" |
| 54 | 60" | 65" | 55-1/8" | 71-1/2" | 39" | 32-1/2" | 52" |
| 60 | 66" | 71" | 61-1/8" | 74-1/2" | 42" | 32-1/2" | 55" |
Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.
Standard Accessories
| Roof Curb | |
| Outlet Guard | |
| Inspection Door | |
| Magnetic Latches | |
| Heat/Smoke Vent | |
| Disconnect Switch |
